BFT gate openers use 433.92 MHz. That’s one of the six bands HomeLink supports, so the pairing is possible — but there’s a step most guides leave out, and missing it is why the vast majority of BFT-HomeLink attempts fail on the first try.

What BFT Is and Why the Frequency Matters

BFT is an Italian gate automation brand, part of the FAAC Group. Their operators — PHOBOS for swing gates, DEIMOS for slide gates, KUSTOS for underground rams — are common in high-end residential installs in California, Florida, and Texas, where single-family driveways with iron or aluminum swing gates are the norm.

The frequency matters because HomeLink has to match the carrier wave before it can transmit anything useful. BFT’s US-market remotes run at 433.92 MHz. Check the label inside the battery compartment of your original BFT transmitter — the frequency is printed on the sticker. If it says 433 MHz (sometimes written 433.92 MHz or 433 Mhz), you’re in the right place. A small number of older BFT models used 303 or 418 MHz; those pair the same way.

For a broader explanation of why frequencies matter and how HomeLink maps to the six RF bands, see How HomeLink Works, and Why It Fails on Driveway Gates.

Fixed-Code vs. Rolling Code: Which BFT Do You Have?

BFT makes both. Entry-level residential BFT models and some older units use a fixed code — the same signal every press. Current PHOBOS AC and DEIMOS BT models ship with rolling code, where each button press sends a unique code drawn from a shared counter.

The quick test: press your original BFT remote twice. If the gate operator opens reliably both times, rolling code is working. If the gate opens once then needs a second press to “catch up,” that’s also rolling code drift — typical of a system where the remote has been pressed many times out of range. If you’re not sure, assume rolling code and use the two-step method below. It works on fixed-code BFT too.

Standard Pairing: Fixed-Code BFT

  1. Choose a HomeLink channel (button 1, 2, or 3 on the visor) and hold it until the indicator LED flashes slowly — about 20 seconds on most vehicles.
  2. Without releasing the HomeLink button, hold the original BFT transmitter within a few inches of the HomeLink module.
  3. Keep both held until the HomeLink LED shifts from a slow flash to a rapid flash. Release both.

Drive to the gate and press the HomeLink button. If the gate moves, you’re done.

Rolling-Code BFT: The Two-Step Procedure

The standard pairing above captures the signal format. For rolling code, you also need to synchronize the counter between HomeLink and the BFT receiver. That happens at the gate operator.

Step 1 — In the car:

  1. Hold the HomeLink button until the LED flashes slowly.
  2. Hold the original BFT transmitter near HomeLink.
  3. Wait for the rapid-flash confirmation. Release both.

Step 2 — At the gate operator (within 2 minutes):

  1. Locate the programming button on the BFT control board. It’s typically labeled PROG, P, or T, and sits beside a small LED indicator. Refer to the operator’s installation manual for the exact location on your model — it’s usually on the main board behind the cover plate.
  2. Press and hold the PROG button until the LED blinks (the number of blinks varies by model, usually 2–3). This puts the receiver into learn mode.
  3. Return to the car and press the HomeLink button once.

The BFT receiver LED will flash to confirm it stored the new code. Press HomeLink from the driver’s seat. The gate should open.

If you have a short driveway and can stay in sight of the gate operator during step 2, bring a second person to stand at the operator while you press HomeLink from the car. On a longer driveway, walk back to the car within the 2-minute learn-mode window.

For the same two-step process applied to FAAC operators (which share similar control board architecture as part of the same FAAC Group), see How to Pair HomeLink to a FAAC Gate Opener.

Why the Gate Stops Responding After a Few Weeks

Rolling code drift is the most common explanation. If the HomeLink button gets pressed when the car is away from the gate — accidentally in a pocket, or while driving past — the HomeLink counter increments but the gate receiver doesn’t hear it. After enough skipped presses, the gate treats HomeLink as out of sync and ignores it.

Fix: delete the HomeLink channel (on most vehicles, hold the two outer buttons simultaneously until the LED flashes twice, which clears all channels; some vehicles have a per-channel delete). Re-pair from scratch using the two-step method.

For a full walkthrough of the rolling code pairing process and what causes sync to break, HomeLink Rolling Code Gate Opener Programming (Two Steps) covers it in detail.

Less common: the BFT receiver’s memory is full. Most BFT receivers hold 250 or more code slots, but installs with many years of added and deleted remotes can accumulate ghost entries. The fix is to clear the receiver memory via the programming menu (steps in the BFT installation manual for your specific model) and re-program all remotes.

Two Cars, One BFT Gate

Each car programs its own HomeLink channel. BFT stores each code independently — there’s no conflict between a first and second vehicle. Repeat the pairing procedure from the second car the same way you did the first.

The one thing that doesn’t share: the learn-mode window. Each car’s programming requires its own PROG button press at the gate operator. You can’t do both cars in one gate-operator session.

Range Problems at the Street

BFT’s 433.92 MHz remotes typically reach 50–100 meters in open air. HomeLink’s integration with a BFT system will have similar range, though dense masonry pillars, wrought iron gates, and the car’s own body can reduce it. Symptoms: HomeLink works from the end of the driveway but not from the street.

The usual fix is positioning — pull slightly closer before pressing. If the range mismatch is structural and pulling closer isn’t practical, How Residential Gate Openers Work - The Four Parts explains the receiver sensitivity variables that are sometimes adjustable in the gate’s programming menu.

If the underlying problem is that the RF link is too fragile for your specific driveway, there’s a newer category of gate access that removes the button entirely and triggers from the car’s GPS position. Proxly is currently in beta.

Frequently asked questions

Does HomeLink work with BFT gate openers?
Yes. BFT gate openers use 433.92 MHz, one of the six bands HomeLink supports. Fixed-code BFT models pair with the standard one-step method. Rolling-code models need the two-step procedure: train HomeLink with the original remote, then press the PROG button on the gate operator to complete the sync.
What frequency does a BFT gate opener use?
Most BFT gate openers sold in the US operate at 433.92 MHz. A small number of older BFT models used 303 MHz or 418 MHz. Check the label inside your original BFT transmitter's battery compartment — the frequency is printed there.
My BFT opener has rolling code. Will HomeLink pair with it?
Yes, with an extra step at the operator. After the standard HomeLink training, go to the gate operator's control board and press the PROG or learn button until the LED flashes. Return to the car and press HomeLink once. This exchanges the rolling code key between both sides.
HomeLink paired but the gate still doesn't respond. What now?
The most common cause is an incomplete rolling-code handshake — the pairing captured the signal format but the PROG step was skipped or timed out. Delete the HomeLink channel and re-pair using the full two-step method. If it still fails, check whether the BFT receiver's memory is full and clear unused code slots.
How do I add a second car to the same BFT gate?
Repeat the pairing procedure from the second car. BFT receivers store each HomeLink channel as a separate entry — there's no conflict. Most BFT receivers hold 250 or more code slots, so adding a second car won't displace the first.
